Technical Data
|
Model |
Ant-800G1-US |
Ant-800G1-EU |
|
Input (DC) |
||
|
Recommended Input Power (Wp) |
210 to 500W+ (2 Pieces) |
|
|
Max. Input DC Voltage (Vdc) |
60 |
|
|
MPPT Voltage Range (Vdc) |
25~55 |
20~55 |
|
Start-up Voltage (Vdc) |
20 |
|
|
Max. Input Current (A) |
13.5×2 |
|
|
Max. DC Short Circuit Current (A) |
16.5×2 |
|
|
Output (AC) |
||
|
Rated Output Power (W) |
800 |
|
|
Max. Output Current (A) |
4 |
3.5 |
|
Nominal Grid Voltage (V) |
220 |
230 |
|
Grid Voltage Range (V) |
184~253 |
|
|
Nominal Frequency (Hz) |
60 |
50 |
|
Frequency Range (Hz) |
55~65 |
45~55 |
|
Power Factor |
0.99 (default), -0.95 (lagging), +0.95 (leading) |
|
|
Maximum Units per Branch |
4 |
|
|
Efficiency |
||
|
CEC Weighted Efficiency |
95.50% |
|
|
Peak Inverter Efficiency |
96.00% |
|
|
MPPT Track Efficiency |
>99.50% |
|
|
Night Time Power Consumption (mW) |
<50 |
|
|
Mechanical Data |
||
|
Operation Temperature Range (°C) |
-40~65 |
|
|
Dimension (mm) |
260Wx225Hx32D |
|
|
Weight (kg) |
2.9 |
|
|
Cooling |
Natural cooling |
|
|
Noise (dB) |
<15 |
|
|
Protection Degree |
IP67 |
|
|
General |
||
|
Display |
LED, APP |
|
|
Communication |
Built-in Wifi |
|
|
Compliance |
IEC 62109, IEC 61000, VDE4105 |
|
Product Details
Different energy meets the vast majority of scenarios. We provide on-site installation and usage guidance services, making it easy for you to buy and use.
Product Introduction
If you have any questions during the browsing process, please feel free to contact us and communicate with us at any time.
IP67 Protection Degree
ZDX microinverter is designed with an IP67 protection degree, ensuring excellent resistance to dust and water. It is well-suited for outdoor installations, providing reliable performance even in challenging environments.
Individual MPPT Tracking
Each microinverter is equipped with independent Maximum Power Point Tracking (MPPT) function that tracks and optimizes the output of the solar panels in real time to maximize power generation efficiency.
